Ignition Zundapp 517

• Flywheel
• For Bosch pointing ignition
• Clockwise
• Fits Puch Maxi


• See images for sizes

• Contact ignition
• Model like Bosch ( Remake )
• Includes extra coil 3 Watt ( Small light )
• 6 Volts 5/15W
• Without flywheel
• Outer diameter Base plate: 90MM
• Inner diameter Base plate: 18MM
• Zundapp / Kreidler / Puch

  Connection

• Black wire = Stopper
• Yellow wire = Headlight and Taillight
• Green wire = Brake light
• Grey or brown wire = Assistance coil - to Taillight up to 3 watts

• Spark coil
• Model Bosch
• Distance mounting holes 54MM
  Fits on;
• Kreidler
• Zundapp
• Puch
• See images for dimensions

• Light coil
• Model BOSCH
• Type with two wires
• 6V
• 5W / 15W

  Fits on;
• Zundapp
• Kreidler
• Puch


• See images for sizes

• Light coil
• Model Bosch
• 6 Volt / 15 Watt
• Single thread

  Fits on:
• Puch
• Zundapp
• Kreidler


• See images for sizes

• Assistance Coil for Bosch ignition
• Wire of this coil can be directly connected to the Taillight to prevent burning out.
• 6 Volt / 3 Watt
• Zundapp
• Kreidler
• Puch


• See images for sizes

• Condenser EFFE
• Solder Model
• Heightened
  Height: 31MM
  Diameter: 18MM
• Bosch model

• Zundapp
• Kreidler
• Puch

• Condenser
• Heightened
• Solder model
• Original Bosch
  Height: 32MM
  Diameter: 18MM
• Zundapp
• Kreidler
• Puch

• Condenser
• Solder
• Bosch model
  Height: 22MM
  Diameter: 18MM

• Puch Maxi
• zundapp
• Kreidler

Contact set Bosch

Contact set

• Contact set
• For a Bosch ignition
  Fits on:
• Kreidler
• Zundapp

• Cylinder screw
• M4X16
• Galvanized
• Din 7985H

M4 Vault lock washer Galvanized.
Din 137A

Flywheel nut

• Zundapp
• A piece

• Woodruff / Flywheel key
• Kreidler
• Zundapp
• Puch


• See images for sizes



Identical to Kreidler article number
00.80.01

Identical to Zundapp article number
DIN6888-300

Ignition Grommet Double.

• Zundapp 4/5 Gear

Identical to Zundapp article number
276-07.101

Ignition grommet.

• Zundapp 3 Gears.

Identical to Zundapp article number
Z265-07 100

Sparkplug NGK

• Short shaft.
• Type NGK B8HS

Sparkplug NGK

• Short shank.
• Type NGK B6HS

Sparkplug NGK

• Short shank
• Type NGK B7HS

Sparkplug cap metal.
Usable for:

• Zundapp

• Kreidler

• Yamaha

• Puch

• Spark plug cap NGK Black
• Type LB05F
• 5K Ohm resistor

  Usable for;

• Zundapp
• Kreidler
• Puch
• Yamaha
• Gilera Citta / SI
• Vespa Ciao
• Tomos
