1 - 50CC Cylinder KTT Kreidler Super
- Cylinder Kreidler KTT
- Superbreitwand ( Wide tap )
- 40MM / 50CC KTT
- 6.25HP
Set comes with;
- Piston, Piston pin 14MM
- Head & base gasket
DKK 1,318.13 | |
1 - Cylinder Kreidler 40MM Super - Booster Ports
- Cylinder
- 40MM / 50CC
- Kreidler superbreitwand
- Wide holes ( 55MM )
- With piston
- Piston pin 14MM
- With base & head gasket
- Connection exhaust 32MM
- Piston with L-ring
- 12 HP is achievable
- Brand N/C - New Competition
DKK 1,708.11 | Out of stock |
2 - Intake Gasket Kreidler 5G BAC
- Intake gasket
- BAC
- Kreidler 5 Gears
- See images for sizes
DKK 7.72 | |
3 - Intake manifold Kreidler Parmakit 19X24MM
- Manifold
- Kreidler
- Parmakit
- For angled intake
- 19X24
- Pass 19MM
- Connection carburettor 24M
DKK 295.99 | |
4 - Base gasket Kreidler 5 Gears 0.50MM Base gasket Kreidler 5 Gears.
Note, for a wide plug. ( 5 Gears )
0.50 MM
DKK 15.21 | |
4 - Base gasket Kreidler 5G 0.25MM
- Base gasket
- 0.25MM
- Note, for wide holes
- Kreidler 5 Gears
DKK 14.04 | |
5 - Ruffled spring washer M6 Galvanized Din 137A
- Ruffled spring washer
- M6
- Blue galvanized
- Din 137A
DKK 0.62 | |
6 - M6 Nut Galvanized Din 934
- Nut M6
- Galvanized
- Din 934
DKK 0.31 | |
7 - Piston 40mm (C) Meteor Kreidler Double Ring
- Meteor piston Kreidler
- 40MM
- Model with double piston ring
- Upper ring is a L-ring
- Tolerance ; C ( 39.960MM )
- Pin 14MM
- See images for sizes
DKK 311.59 | |
7 - Piston 40mm (L) Meteor Kreidler Double Ring
- Piston Meteor
- Kreidler
- 40MM
- Piston with double ring, upper ring is a L-ring
- Tolerance size L
- Pin 14MM
DKK 311.59 | Out of stock |
7 - Piston 40mm (G) Meteor Kreidler Double Ring
- Meteor Piston Kreidler
- 40MM
- Model with double piston ring
- Upper ring is a L-ring
- Tolerance ; G ( 39.980MM )
- Pin 14MM
DKK 311.59 | |
7 - Piston 40mm (N) Meteor Kreidler Double Ring
- Piston Meteor
- Kreidler
- 40MM
- Piston with double ring, upper ring is a L-ring
- Tolerance Size N
- Pin 14MM
DKK 311.59 | |
7 - Piston 40mm (K) Meteor Kreidler Double Ring
- Meteor piston Kreidler
- 40MM
- Model with double piston ring
- Upper ring is a L-ring
- Tolerance ; K ( 39.995MM )
- Pin 14MM
DKK 311.59 | |
7 - Piston 40mm (D) Meteor Kreidler Double Ring
- Meteor piston Kreidler
- 40MM
- Model with double piston ring
- Upper ring is a L-ring
- Tolerance ; D ( 39.965MM )
- Pin 14MM
DKK 311.59 | |
7 - Piston 40mm (M) Meteor Kreidler Double Ring
- Piston Meteor
- Kreidler
- 40MM
- Piston with double ring, upper ring is a L-ring
- Tolerance Size M
- Pin 14MM
DKK 295.99 | |
7 - Piston 40mm (A) Meteor Kreidler Double Ring
- Meteor piston Kreidler
- 40MM
- Model with double piston ring
- Upper ring is a L-ring
- Tolerance; A ( 39.95MM )
- Pin 14MM
DKK 311.59 | |
7 - Piston 40mm (H) Meteor Kreidler Double Ring
- Meteor piston Kreidler
- 40MM
- Model with double piston ring
- Upper ring is a L-ring
- Tolerance ; H ( 39.985MM )
- Pin 14MM
DKK 300.29 | Out of stock |
7 - Piston 40mm (E) Meteor Kreidler Double Ring
- Meteor piston Kreidler
- 40MM
- Model with double piston ring
- Upper ring is a L-ring
- Tolerance ; E ( 39.970MM )
- Pin 14MM
DKK 311.59 | |
7 - Piston 40mm (O) Meteor Kreidler Double Ring
- Piston Meteor
- Kreidler
- 40MM
- Piston with double ring, upper ring is a L-ring
- Tolerance Size O
- Pin 14MM
DKK 311.59 | |
7 - Piston 40mm (B) Meteor Kreidler Double Ring
- Meteor piston Kreidler
- 40MM
- Model with double piston ring
- Upper ring is a L-ring
- Tolerance; B ( 39.955MM )
- Pen 14MM
DKK 311.59 | |
7 - Piston 40mm (I) Meteor Kreidler Double Ring
- Meteor Piston Kreidler
- 40MM
- Model with double piston ring
- Upper ring is a L-ring
- Tolerance ; I ( 39.990MM )
- Pin 14MM
DKK 311.59 | |
7 - Piston 40mm (F) Meteor Kreidler Double Ring
- Meteor piston Kreidler
- 40MM
- Model with double ring
- Upper ring is a L-ring
- Tolerance; F ( 39.975MM )
- Pin 14MM
DKK 308.09 | Out of stock |
8 - Piston Ring Kreidler 40X1.5B
- Piston ring
- Kreidler
- 40MM X 1.5
- B-lock
DKK 23.01 | |
9 - Piston Ring Kreidler 40X2B L-Ring
- Piston ring Kreidler
- 40 X 2 BL ( L-ring )
DKK 69.80 | |
10 - Piston pin Kreidler 14X33MM Mahle
- Piston pin Mahle
- 14 X 33MM
- Kreidler
- For 40MM Pistons
DKK 101.00 | |
11 - Piston pin clip 14MM Kreidler A piece
- Piston pin clip
- 14MM
- A Piece
- Kreidler
DKK 3.51 | |
12 - Cylinder head Kreidler 5G KTT Super 40MM
- Cylinder head KTT
- 40MM / 50CC
- For Super Breitwand ( Wide plug )
- Piston pin 14MM
- Without damping rubbers
- Kreidler 5 Gears
DKK 694.16 | |
13 - M8 Washer Galvanized Din 125A M8 Washer
Galvanized
Din 125A DKK 0.39 | |
14 - M8 Nut Galvanized Din 934
- Nut M8
- Galvanized
- Din 934
DKK 0.55 | |
|
15 - Sparkplug Bosch W7AC Sparkplug Bosch.
- Type W7AC ( W175T1 )
- ( Matches with a NGK B6HS )
- Short shaft
DKK 29.25 | |
16 - Sparkplug cap Suppressed 1K ohm
- Sparkplug cap
- Model as BERU
- Suppressed 1K ohm
To use for;
- Zundapp
- Kreidler
- Puch
DKK 85.40 | |
16 - Sparkplug cap metal Sparkplug cap metal.
Usable for:
- Zundapp
- Kreidler
- Yamaha
- Puch
DKK 38.61 | |
17 - Grommet Sparkplug cap Merit
- Grommet
- Merit Sparkplug cap
DKK 23.32 | |
18 - Head gasket 50CC Kreidler 5G
- Head gasket
- 50CC / 40MM
- Note, for wide plug
- Kreidler 5 Gears
DKK 19.42 | |
