Technical drawing Side panels Tomos Flexer

Grouped product items
Product Name	Qty
2 - Hex bolt M8X55 Galvanized Din 931 Hex bolt M8X55 Verzinkt Full thread Din 931 DKK 2.73
3 - M8 Washer Galvanized Din 125A M8 Washer Galvanized Din 125A DKK 0.39
4 - M8 Locknut Galvanized Din 985 M8 Locknut Galvanized Din 985 DKK 1.17
6 - Exhaust Tomos A35 / 22MM Black Exhaust standard model Tomos A35 22MM Additional Warranty Information, see Downloads DKK 327.19
6 - Exhaust Tomos A3 Speedy 26MM Chrome Exhaust Standard model Model Speedy Chromed 26MM Tomos A3 Additional Warranty Information, see Downloads DKK 389.59
6 - Exhaust Tomos A35 / 22MM Chrome Exhaust Standard model Chromed 22MM Tomos A35 Additional Warranty Information, see Downloads DKK 350.98
8 - Plate Screw Galvanized 3.9 X 9.5 Din 7981 Plate Screw Galvanized. 3.9 X 9.5. Din 7981 DKK 0.79
9 - Exhaust gasket Tomos Standard Exhaust gasket Standard Tomos DKK 5.85
9 - Exhaust gasket Tomos Big Exhaust gasket Big Tomos DKK 10.14
10 - M6 Spring washer Flat Galvanized Din 127 M6 Spring washer Flat Galvanized Din 127 DKK 0.15
11 - Exhaust nut brass M6 Tall Model Exhaust nut Brass M6 ( tall model ) A Piece Usable for: Puch Tomos Kreidler DKK 7.72
11 - M6 Nut Galvanized extended 3D Extentend nut M6 / 3D Galvanized Ideal to use for exhaust studs or as cylinder head nut 6MM A piece DKK 3.12
12 - Hex bolt M6X16 Galvanized Din 933 Hex bolt M6 X 16 Galvanized Full thread Din 933 DKK 0.55
13 - M6 Washer Galvanized Din 125A M6 Washer Galvanized Din 125A DKK 0.39
15 - M6 Nut Galvanized Din 934 Nut M6 Galvanized Din 934 DKK 0.31
18 - Flange bolt Tomos M6X16 Flange bolt M6X16 A Piece Fits on; Side panel Tomos Standard Rear carrier Tomos DKK 3.12
19 - Flat washer Tomos M6 Flat washer For Tomos Side panels M6 ( Outer diameter 18MM ) Galvanized DKK 3.12
20 - Rubber Side cover / Grommet cable Oil Sensor Tomos Rubber Side cover Tomos Can be used as grommet for the oil sensor cable See extra images DKK 17.86
22 - Plate Screw Galvanized 4.2 X 19 Din 7981 Plate Screw Galvanized Size: 4.2 X 19 Din 7981 DKK 1.17
23 - M4 Washer Galvanized Din 125A M4 Washer. Galvanized. Din 125A DKK 0.39
24 - Chainguard Tomos A35 Black Chainguard Black Tomos A35 DKK 97.50
25 - Plate Screw Galvanized 4.8X13 Din 79676C Plate Screw Hexagonal. Galvanized. Size; 4.8X13 Din 7976C DKK 3.12
26 - Flat washer Tomos M5 Flat washer Tomos Chainguard M5 Outer diameter 15MM DKK 1.56
